BELARUS-651

01 March 2024, New Delhi: This tractor is intended for various agricultural operations coupled with mounted, semi-mounted and trailed machines, for hauling operations and for operations in industry.

Small dimensions, high road clearance, final drive with planetary gear group.

Environmental standard Stage IIIa.

Model : LOMBARDINI / CATERPILLAR

Power, kW (h.p.) : 46 (62, 5) / 45, 5 (62)

Technical characteristics:

ENGINE
Type	four-stoke diesel engine
Model	«LOMBARDINI» LDW2204T/CATERPILLAR C2.2 GP61B
Power, kW (h.p.)	46(62,5)/45,5(62)
Crankshaft rated speed, rpm	3000
Number of cylinders, pcs.	4
Displacement, l	2, 2
Maximum torque, Nm	174 / 189, 1
Specific fuel consumption at operating power, g/kWh	329/324
Factor of torque backup, %	18/30
Fuel tank capacity, l	45
TRANSMISSION
Clutch	dry, single-disk
Gearbox	mechanical, with easy-engagement clutches
Number of gears: forward/reverse	16/8
Travel speed: forward/reverse, km/h	1,3-40/2,3-21,6
Rear PTO:
Continuous I, rpm	540
Continuous II, rpm	1000 (+continuous III, PTO 540e)
Ground-speed I, rev/m of travel	2, 9
ground-speed II, rev/m of travel	5,4 or 3,7
HYDRAULIC LIFT LINKAGE
Versatile, remote-cylinder
Lifting capacity at suspension point, kg	1700
Maximum pressure, MPa	20
Pump performance,l/min	40
Hydraulic system capacity, l	19
DIMENSIONS AND WEIGHT
Overall length, mm	3270
Width, mm	1675
Height to cabin top, mm	2260
Tractor base, mm	1900
Track, mm:
Front Wheels	1260,1410
Rear Wheels	1300, 1350, 1450, 1520, 1620
Agrotechnical clearance, mm	470
Least turning radius, m	3,8
Operating weight, kg	3000
Tire Sizes:
Front Wheels	9,50-20
Rear Wheels	14.9R24
Wheel Arrangement	4×4

Additional Options

• Front lift linkage;
• Front PTO with shaft shank;
• Front ballast weights;
• Hitch hoses;
• TSU-1M tow hitch;
• Bracket with cutoff clutches;
• Economical PTO 540e.
